Specifications
- ECCN Kodu
- EAR99
- Contact Materials
- BRASS
- Contact Pattern
- RECTANGULAR
- Contact Gender
- FEMALE
- Insulation Materials
- GLASS FILLED LIQUID CRYSTAL POLYMER
- Pozisyon Sayısı
- 34
- Body Length Or Diameter
- 0.378 inch
- Özellikler
- Solder Retention
- Plating Thickness
- 8μin
- Contact Finish
- Gold
- Yayın Yılı
- 2007
- Mounting Option1
- LOCKING
- Operating Temperature Max
- 85°C
- Pcb Contact Pattern
- RECTANGULAR
- Height Above Board
- 0.041 1.05mm
- Parça Durumu
- Active
- Reference Standard
- UL
- Insulation Resistance
- 100000000Ohm
- Montaj Tipi
- Surface Mount
- Sıra Sayısı
- 2
- Stack Height Mating
- 1.3mm
- Number Of Conductors
- ONE
- Board Mounting Option
- FITTING NAIL
- RoHS Durumu
- ROHS3 Compliant
- Rated Current Signal
- 0.3A
- Number Of Pcb Rows
- 2
- Connector Type
- Plug, Outer Shroud Contacts
- Polarization Key
- POLARIZED HOUSING
- Insulator Color
- BLACK
- Dielectric Withstanding Voltage
- 350VAC V
- Contact Resistance
- 40mOhm
- Body Depth
- 0.041 inch
- Reliability
- COMMERCIAL
- Fabrika Tedarik Süresi
- 21 Weeks
- Durability
- 30 Cycles
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Pitch
- 0.016 0.40mm
- Total Number Of Contacts
- 34
- Ambalaj
- Tape & Reel (TR)
- Contact Finish Thickness
- 8.00μin 0.203μm
