Volume pricing
- 1+ pcs$0.58
- 10+ pcs$0.55
- 100+ pcs$0.51
- 500+ pcs$0.49
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Number Of Conductors
- ONE
- Mating Contact Pitch
- 0.039 inch
- Parça Durumu
- Active
- Sıra Sayısı
- 1
- Pcb Contact Pattern
- RECTANGULAR
- Reliability
- COMMERCIAL
- Contact Finish Mating
- Tin
- Pitch Mating
- 0.039 1.00mm
- JESD-609 Kodu
- e3
- Mil Conformance
- NO
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Shrouding
- Shrouded - 4 Wall
- Connector Type
- Header
- Insulation Materials
- Polyamide (PA46), Nylon 4/6
- Number Of Positions Loaded
- All
- Insulation Color
- Natural
- Ambalaj
- Tape & Reel (TR)
- Total Number Of Contacts
- 5
- Number Of Pcb Rows
- 1
- Contact Finish Thickness Mating
- 40.0μin 1.02μm
- Contact Type
- Male Pin
- Body Length Or Diameter
- 0.276 inch
- Iec Conformance
- NO
- Operating Temperature Min
- -40°C
- Contact Materials
- Phosphor Bronze
- Contact Shape
- Square
- Pozisyon Sayısı
- 5
- Filter Feature
- NO
- Reference Standard
- UL
- Montaj Tipi
- Surface Mount
- Material Flammability Rating
- UL94 V-0
- Contact Resistance
- 20mOhm
- Terminal Adımı
- 0.9906mm
- Kurşunsuz Kodu
- yes
- RoHS Durumu
- ROHS3 Compliant
- Mounting Option1
- LOCKING
- Seri
- Pico-Clasp 501331
- Yayın Yılı
- 2007
- Özellikler
- Pick and Place, Solder Retention
- Fabrika Tedarik Süresi
- 17 Weeks
