5008730806

Specifications

Insulator Color

BLACK

Nem Hassasiyeti (MSL)

1 (Unlimited)

Number Of Conductors

ONE

Contact Pattern

RECTANGULAR

Contact Gender

MALE

Mating Contact Pitch

0.043 inch

Bodyshell Style

RECEPTACLE

Additional Feature

ROHS COMPLIANT & TAPE PACKAGE

Operating Temperature Min

-25°C

Rated Current Signal

0.5A

Contact Materials

NOT SPECIFIED

Card Type

Secure Digital - microSD™

Mil Conformance

NO

Pozisyon Sayısı

8

Mounting Feature

Normal, Standard - Top

Insertion Removal Method

Push In, Push Out

Reference Standard

UL

Number Of Pcb Rows

1

Yayın Yılı

2011

Insulation Materials

LIQUID CRYSTAL POLYMER (LCP)

Sıra Sayısı

1

Fabrika Tedarik Süresi

15 Weeks

Insulation Resistance

1000000000Ohm

Ambalaj

Tape & Reel (TR)

Connector Type

Connector and Ejector

Terminal Adımı

1.0922mm

Contact Style

COMPRESSION

Dielectric Withstanding Voltage

500VAC V

Din Conformance

NO

Contact Finish

Gold

Montaj Tipi

Surface Mount, Right Angle

Option

GENERAL PURPOSE

Contact Resistance

100mOhm

Durability

5000 Cycles

RoHS Durumu

ROHS3 Compliant

Kurşunsuz Kodu

yes

Contact Finish Thickness

20.0μin 0.51μm

Pcb Contact Pattern

RECTANGULAR

Parça Durumu

Obsolete

Body Breadth

0.074 inch
