5000751517

Specifications

Ul Flammability Code

94V-0

Polarization Key

POLAR PIN POSITION

Parça Durumu

Active

Connector Type

USB - mini B

Number Of Pcb Rows

2

JESD-609 Kodu

e3

Mounting Option1

LOCKING

Body Depth

0.303 inch

Terminal

Solder

Nominal Gerilim

30VAC/DC

Option

GENERAL PURPOSE

Contact Materials

NOT SPECIFIED

Contact Finish

Gold

Length Termination

0.078 inch

Mil Conformance

NO

Gender

Receptacle

Body Length Or Diameter

0.303 inch

Filter Feature

NO

Iec Conformance

NO

Number Of Conductors

ONE

Board Mounting Option

LOCATING POSTS

Pcb Contact Pattern

STAGGERED

Shellshielding Material

Copper Alloy

Montaj Tipi

Through Hole

Insulation Materials

GLASS FILLED POLYETHYLENE

Seri

500075

Shielding

Shielded

Ambalaj

Tray

Reference Standard

UL

Specifications

USB 2.0 OTG

Empty Shell

NO

Çalışma Sıcaklığı

-40°C~85°C

Number Of Ports

1

Current Rating Amps

1A

Din Conformance

NO

Material Flammability Rating

UL94 V-0

Contact Style

USB, SER B SQ

Fabrika Tedarik Süresi

11 Weeks

Mixed Contacts

NO

RoHS Durumu

ROHS3 Compliant
