Specifications
- Kurşunsuz Kodu
- yes
- Contact Materials
- NOT SPECIFIED
- Filter Feature
- NO
- Body Length Or Diameter
- 0.305 inch
- Durability
- 10 Cycles
- Reliability
- COMMERCIAL
- Option
- GENERAL PURPOSE
- Rated Current Signal
- 0.1A
- Mounting Option2
- FRICTION LOCK
- Din Conformance
- NO
- Seri
- SlimStack 500024
- Contact Resistance
- 90mOhm
- Contact Pattern
- RECTANGULAR
- Insulation Resistance
- 100000000Ohm
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Pitch
- 0.016 0.40mm
- Contact Style
- BELLOWED TYPE
- Pozisyon Sayısı
- 24
- Ambalaj
- Tape & Reel (TR)
- Number Of Conductors
- ONE
- Pcb Contact Pattern
- RECTANGULAR
- Height Above Board
- 0.037 0.95mm
- Insulation Materials
- LIQUID CRYSTAL POLYMER (LCP)
- Board Mounting Option
- FITTING NAIL
- Contact Gender
- FEMALE
- Parça Durumu
- Obsolete
- Contact Finish Thickness
- 3.94μin 0.10μm
- Total Number Of Contacts
- 24
- Stack Height Mating
- 0.95mm
- Operating Temperature Max
- 85°C
- ECCN Kodu
- EAR99
- Montaj Tipi
- Surface Mount
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Özellikler
- Solder Retention
- Body Depth
- 0.037 inch
- Body Breadth
- 0.197 inch
- Mounting Option1
- LOCKING
- Insulator Color
- BEIGE
- HTS Kodu
- 8536.69.40.40
- Yayın Yılı
- 2010
