Specifications
- Montaj
- Through Hole
- HTS Kodu
- 8536.69.40.40
- Kurşunsuz Kodu
- yes
- Yayın Yılı
- 2008
- Maks. Çalışma Sıcaklığı
- 105°C
- Max Voltage Rating Ac
- 250V
- Rated Current Signal
- 5A
- Contact Gender
- Male
- Genişlik
- 11.9mm
- Voltage Rated Dc
- 250V
- Terminal
- Solder
- Contact Style
- SQ PIN-SKT
- Option
- GENERAL PURPOSE
- Insertion Forcemax
- 11.5648 N
- Dielectric Withstanding Voltage
- 1500VAC V
- Number Of Contacts
- 12
- Polarization Key
- POLARIZED HOUSING
- Glow Wire Compliant
- Non-compliant
- Contact Materials
- Brass
- Lead Length
- 3.3mm
- Lead Pitch
- 3mm
- Row Spacing Mating
- 2.9972 mm
- Parça Durumu
- Active
- Additional Feature
- POLARIZED
- Housing Material
- Nylon
- Contact Plating
- Tin
- Renk
- Black
- Sıra Sayısı
- 2
- Reference Standard
- UL
- Min. Çalışma Sıcaklığı
- -40°C
- Body Depth
- 0.457 inch
- Withdrawl Forcemin
- 3.614 N
- Orientation
- Vertical
- Reliability
- COMMERCIAL
- Iec Conformance
- NO
- Filter Feature
- NO
- Pitch
- 3mm
- Connector Type
- Male Pin
- ECCN Kodu
- EAR99
- RoHS Durumu
- RoHS Compliant
