Specifications
- Plating Thickness
- 30μin
- Voltage Rated Dc
- 600V
- Pitch
- 4.2mm
- Gender
- Female
- Body Depth
- 0.5 inch
- Contact Gender
- Male
- Connector Type
- Male Pin
- Empty Shell
- NO
- Option
- GENERAL PURPOSE
- Number Of Conductors
- ONE
- Iec Conformance
- NO
- Fabrika Tedarik Süresi
- 8 Weeks
- Kurşunsuz Kodu
- yes
- Durability
- 30 Cycles
- Parça Durumu
- Active
- Polarization Key
- HOUSING SIDE
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Flammability Rating
- UL94 V-0
- Number Of Contacts
- 16
- Contact Pattern
- RECTANGULAR
- Bodyshell Style
- RECEPTACLE
- Halogen Free
- Low Halogen
- Yayın Yılı
- 2008
- Orientation
- Vertical
- RoHS Durumu
- RoHS Compliant
- Contact Resistance
- 10mOhm
- Contact Style
- SQ PIN-SKT
- Contact Plating
- Gold
- JESD-609 Kodu
- e3
- Mil Conformance
- NO
- Ul Flammability Code
- 94V-0
- Glow Wire Compliant
- Non-compliant
- Lead Pitch
- 4.2mm
- Radyasyon Dayanımı
- No
- Sıra Sayısı
- 2
- Fastening Type
- Ramp
- Maks. Çalışma Sıcaklığı
- 105°C
- Rated Current Signal
- 9A
- Filter Feature
- NO
- Min. Çalışma Sıcaklığı
- -40°C
