39-01-4052

Specifications

Iec Conformance

NO

Ambalaj

Bulk

Wire Gauge Min

20 AWG

Radyasyon Dayanımı

No

Fabrika Tedarik Süresi

8 Weeks

Terminal

Crimp

Empty Shell

NO

Mating Information

MULTIPLE MATING PARTS AVAILABLE

Dielectric Withstanding Voltage

2200VAC V

Connector Type

Male Pin, Pin, Plug

Insertion Forcemax

6.672 N

Uzunluk

22.2mm

Akım Değeri

13A

Housing Material

Nylon

Halogen Free

Low Halogen

Total Number Of Contacts

5

Reliability

COMMERCIAL

Max Voltage Rating Dc

600.6kV

Shell Material

POLYAMIDE66

Wire Gauge Max

16 AWG

Option

GENERAL PURPOSE

Ul Flammability Code

94V-2

Mil Conformance

NO

Reach Svhc

Unknown

Gender

Male

Kurşunsuz

Lead Free

Durability

30 Cycles

Parça Durumu

Active

Montaj

Panel, Snap in

Orientation

Straight

Depth

23.9mm

ECCN Kodu

EAR99

Din Conformance

NO

Pitch

4.2mm

Genişlik

7.4mm

Yayın Yılı

2007

Additional Feature

PANEL MOUNTABLE

Number Of Conductors

ONE

Voltage Rated Dc

600V

Min. Çalışma Sıcaklığı

-40°C
