Specifications
- Flammability Rating
- UL94 V-0
- Iec Conformance
- NO
- Ambalaj
- Bulk
- Option
- GENERAL PURPOSE
- Reference Standard
- UL, CSA
- Yayın Yılı
- 2011
- Durability
- 25 Cycles
- Glow Wire Compliant
- Non-compliant
- Bodyshell Style
- RECEPTACLE
- Pitch
- 2.54mm
- ECCN Kodu
- EAR99
- Uzunluk
- 20.1mm
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Voltage Rated Dc
- 250V
- Orientation
- Vertical
- Contact Gender
- Male
- Housing Material
- Nylon
- Renk
- White
- Terminal
- Solder
- Plating Thickness
- 20μin
- Kurşunsuz
- Lead Free
- Montaj
- Through Hole
- Filter Feature
- NO
- Contact Resistance
- 10mOhm
- Maks. Çalışma Sıcaklığı
- 75°C
- Number Of Conductors
- ONE
- Contact Plating
- Gold
- RoHS Durumu
- RoHS Compliant
- Din Conformance
- NO
- Radyasyon Dayanımı
- No
- Connector Type
- Male Pin
- Rated Current Signal
- 4A
- Contact Materials
- Brass
- Yükseklik
- 3.3mm
- Sıra Sayısı
- 1
- Contact Lengthmating
- 7.493mm
- Akım Değeri
- 4A
- JESD-609 Kodu
- e3
- Min. Çalışma Sıcaklığı
- 0°C
- Ul Flammability Code
- 94V-0
