Specifications
- Çalışma Sıcaklığı
- -40°C~105°C
- Fastening Type
- Latch Holder
- Contact Materials
- Brass
- Pitch Mating
- 0.079 2.00mm
- Özellikler
- Solder Retention
- Contact Finish Thickness Post
- 39.4μin 1.00μm
- Contact Type
- Male Pin
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal
- Solder
- Fabrika Tedarik Süresi
- 18 Weeks
- Number Of Positions Loaded
- All
- Style
- Board to Cable/Wire
- Insulation Height
- 0.354 9.00mm
- Shrouding
- Shrouded - 4 Wall
- Current Rating Amps
- Varies by WireGAuge
- Material Flammability Rating
- UL94 V-0
- Applications
- General Purpose
- Row Spacing Mating
- 0.165 (4.20mm)
- Seri
- Spot-On 2.0 201197
- Connector Type
- Header
- Contact Finish Mating
- Tin
- Montaj Tipi
- Surface Mount
- Ambalaj
- Cut Tape (CT)
- Contact Finish Thickness Mating
- 39.4μin 1.00μm
- RoHS Durumu
- ROHS3 Compliant
- Insulation Color
- Natural
- Sıra Sayısı
- 2
- Pozisyon Sayısı
- 30
- Nominal Gerilim
- 250V
- Insulation Materials
- Polyamide (PA), Nylon, Glass Filled
- Contact Shape
- Square
