Specifications
- Contact Finish Mating
- Tin
- Applications
- General Purpose, Industrial, Telecommunications
- Shrouding
- Shrouded - 4 Wall
- Montaj Tipi
- Through Hole
- Orientation
- Vertical
- Seri
- Mini-Fit Jr 172447
- Yayın Yılı
- 2015
- Ambalaj
- Tray
- Montaj
- Through Hole
- Pozisyon Sayısı
- 8
- Terminal
- Solder
- Fastening Type
- Locking Ramp
- Sıra Sayısı
- 2
- Glow Wire Compliant
- Compliant
- Fabrika Tedarik Süresi
- 17 Weeks
- Connector Type
- Header
- Contact Materials
- Brass
- Row Spacing Mating
- 0.165 (4.20mm)
- Contact Type
- Male Pin
- Contact Finish Thickness Post
- 100.0μin 2.54μm
- Insulation Materials
- Polyamide (PA), Nylon
- Parça Durumu
- Active
- Özellikler
- Board Guide, Glow Wire Compliant
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Number Of Positions Loaded
- All
- Style
- Board to Cable/Wire
- Material Flammability Rating
- UL94 V-2
- Kurşunsuz Kodu
- yes
- Insulation Color
- Black
- Insulation Height
- 0.504 12.80mm
- RoHS Durumu
- ROHS3 Compliant
- Contact Shape
- Square
- Pitch Mating
- 0.165 4.20mm
- Contact Finish Thickness Mating
- 100.0μin 2.54μm
- Contact Length Post
- 0.138 3.50mm
