Specifications
- Yayın Yılı
- 2015
- Pitch
- 3.5052mm
- Contact Finish Thickness Post
- 60.0μin 1.52μm
- Contact Shape
- Square
- Contact Finish Thickness Mating
- 60.0μin 1.52μm
- Connector Type
- Header
- Contact Finish Mating
- Tin
- Applications
- Automotive, General Purpose, Industrial, Lighting, Medical, Military, Telecommunications
- Ambalaj
- Bulk
- Material Flammability Rating
- UL94 V-0
- Montaj
- Through Hole
- Montaj Tipi
- Through Hole, Right Angle
- Seri
- Ultra-Fit 172310
- Nominal Gerilim
- 400V
- Çalışma Sıcaklığı
- -40°C~105°C
- Contact Finish Post
- Tin
- Terminal
- Solder
- Shrouding
- Shrouded - 4 Wall
- Contact Materials
- Copper Alloy
- Contact Length Post
- 0.126 3.20mm
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Fabrika Tedarik Süresi
- 13 Weeks
- Insulation Height
- 0.353 8.96mm
- Pitch Mating
- 0.138 3.50mm
- Pozisyon Sayısı
- 4
- Contact Type
- Male Pin
- Number Of Positions Loaded
- All
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- RoHS Durumu
- ROHS3 Compliant
- Contact Plating
- Tin
- Insulation Color
- Natural
- Renk
- Natural
- Sıra Sayısı
- 1
- Style
- Board to Cable/Wire
- Özellikler
- Board Guide
- Fastening Type
- Latch Holder
