Specifications
- Insulation Color
- Black
- Sıra Sayısı
- 2
- Style
- Board to Cable/Wire
- Stack Height Mating
- 26.99mm
- Özellikler
- Board Guide
- Fastening Type
- Latch Holder
- Pitch Mating
- 0.138 3.50mm
- Insulation Height
- 0.465 11.80mm
- Pozisyon Sayısı
- 8
- Number Of Positions Loaded
- All
- Contact Type
- Male Pin
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- RoHS Durumu
- ROHS3 Compliant
- Material Flammability Rating
- UL94 V-0
- Ambalaj
- Tray
- Montaj Tipi
- Through Hole
- Nominal Gerilim
- 400V
- Seri
- Ultra-Fit 172298
- Çalışma Sıcaklığı
- -40°C~120°C
- Shrouding
- Shrouded - 4 Wall
- Contact Finish Post
- Tin
- Terminal
- Kinked Pin, Solder
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Contact Materials
- Copper Alloy
- Contact Length Post
- 0.126 3.20mm
- Fabrika Tedarik Süresi
- 13 Weeks
- ECCN Kodu
- EAR99
- Yayın Yılı
- 2015
- Row Spacing Mating
- 0.181 (4.60mm)
- Contact Finish Thickness Mating
- 15.0μin 0.38μm
- Contact Shape
- Square
- Contact Finish Thickness Post
- 60.0μin 1.52μm
- Connector Type
- Header
- Contact Finish Mating
- Gold
- Applications
- Automotive, General Purpose, Industrial, Lighting, Medical, Military, Telecommunications
