Volume pricing
- 1+ pcs$0.29
- 10+ pcs$0.27
- 100+ pcs$0.26
- 500+ pcs$0.24
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Design
- PREASSEM CONN
- Note
- Contacts Not Included
- Rated Current Signal
- 7A
- Material Flammability Rating
- UL94 V-2
- Card Type
- Non Specified - Single Edge
- Fabrika Tedarik Süresi
- 6 Weeks
- Çalışma Sıcaklığı
- 0°C~75°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Body Depth
- 0.63 inch
- Pitch
- 0.156 3.96mm
- Özellikler
- Latch Lock
- Wire Size Max
- 18 AWG
- Montaj Tipi
- Free Hanging (In-Line)
- Reliability
- COMMERCIAL
- Yayın Yılı
- 2014
- Body Breadth
- 0.3 inch
- Pozisyon Sayısı
- 4
- Wire Size Min
- 20 AWG
- Dielectric Withstanding Voltage
- 1500VAC V
- Insulation Resistance
- 1000000000Ohm
- Reference Standard
- UL,CSA,TUV
- Mounting Option1
- LOCKING
- Card Thickness
- 0.062 1.57mm
- Total Number Of Contacts
- 0+4
- Additional Feature
- CARD EDGE POWER CONNECTOR
- Contact Pattern
- RECTANGULAR
- Contact Style
- BELLOWED TYPE
- Connector Type
- CARD EDGE CONNECTOR
- Sıra Sayısı
- 1
- ECCN Kodu
- EAR99
- RoHS Durumu
- ROHS3 Compliant
- Material Insulation
- Polyamide (PA), Nylon
- Renk
- White
- Parça Durumu
- Active
- Contact Resistance
- 10mOhm
- Seri
- EDGEMATE 172159
- Ambalaj
- Bulk
- Durability
- 25 Cycles
