Specifications
- Shrouding
- Shrouded - 4 Wall
- Yayın Yılı
- 2013
- Material Flammability Rating
- UL94 V-0
- Parça Durumu
- Active
- Terminal
- Solder
- Sıra Sayısı
- 2
- Number Of Contacts
- 12
- Ambalaj
- Tray
- Min. Çalışma Sıcaklığı
- -40°C
- Style
- Board to Cable/Wire
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Orientation
- Vertical
- Maks. Çalışma Sıcaklığı
- 105°C
- Halogen Free
- Low Halogen
- Length Termination
- 0.147 inch
- Kurşunsuz Kodu
- yes
- Body Depth
- 0.583 inch
- HTS Kodu
- 8536.69.40.30
- Seri
- Mega-Fit
- Insulation Height
- 0.583 14.80mm
- Plating Thickness
- 30μin
- Contact Length Post
- 0.147 3.73mm
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Montaj Tipi
- Through Hole
- Contact Type
- Male Pin
- Connector Type
- Header
- RoHS Durumu
- ROHS3 Compliant
- Number Of Conductors
- ONE
- Fabrika Tedarik Süresi
- 12 Weeks
- Özellikler
- Board Guide, Glow Wire Compliant
- Number Of Positions Loaded
- All
- Glow Wire Compliant
- Compliant
- ECCN Kodu
- EAR99
- Row Spacing Mating
- 0.224 (5.70mm)
- Contact Shape
- Square
- Contact Resistance
- 5mOhm
- Reference Standard
- UL, CSA
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Fastening Type
- Locking Ramp
- Pitch Mating
- 0.224 5.70mm
