Specifications
- Kurşunsuz Kodu
- yes
- Length Termination
- 0.147 inch
- HTS Kodu
- 8536.69.40.30
- Body Depth
- 0.583 inch
- Plating Thickness
- 15μin
- Insulation Height
- 0.583 14.80mm
- Seri
- Mega-Fit
- Montaj Tipi
- Through Hole
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Contact Length Post
- 0.147 3.73mm
- Connector Type
- Header
- Contact Type
- Male Pin
- Operating Temperature Min
- -40°C
- RoHS Durumu
- ROHS3 Compliant
- Number Of Conductors
- ONE
- Shrouding
- Shrouded - 4 Wall
- Sıra Sayısı
- 2
- Material Flammability Rating
- UL94 V-0
- Parça Durumu
- Active
- Terminal
- Solder
- Yayın Yılı
- 2013
- Board Mounting Option
- SPLIT BOARD LOCK
- Pozisyon Sayısı
- 12
- Ambalaj
- Tray
- Contact Finish Thickness Mating
- 15.0μin 0.38μm
- Style
- Board to Cable/Wire
- Operating Temperature Max
- 105°C
- Contact Materials
- Copper
- Contact Finish Post
- Tin
- Body Length Or Diameter
- 1.65 inch
- Contact Finish Mating
- Gold
- Contact Finish Thickness Post
- 100.0μin 2.54μm
- Reliability
- COMMERCIAL
- Mixed Contacts
- YES
- Insulation Color
- Black
- Applications
- Automotive, General Purpose, Industrial, Telecommunications
- Insulation Resistance
- 1000000000Ohm
- Özellikler
- Board Guide, Glow Wire Compliant
- Fabrika Tedarik Süresi
- 18 Weeks
- Number Of Positions Loaded
- All
