Specifications
- Contact Resistance
- 5mOhm
- Reference Standard
- UL, CSA
- Contact Finish Thickness Mating
- 15.0μin 0.38μm
- Contact Shape
- Square
- Row Spacing Mating
- 0.224 (5.70mm)
- Style
- Board to Cable/Wire
- Pitch Mating
- 0.224 5.70mm
- Mounting Option1
- LATCH
- JESD-609 Kodu
- e3
- Fastening Type
- Locking Ramp
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Fabrika Tedarik Süresi
- 9 Weeks
- Material Flammability Rating
- UL94 V-0
- Parça Durumu
- Active
- Terminal
- Solder
- Özellikler
- Board Guide, Glow Wire Compliant
- Sıra Sayısı
- 2
- Yayın Yılı
- 2013
- Shrouding
- Shrouded - 4 Wall
- Board Mounting Option
- SPLIT BOARD LOCK
- Ambalaj
- Tray
- Pozisyon Sayısı
- 10
- ECCN Kodu
- EAR99
- Number Of Positions Loaded
- All
- Applications
- Automotive, General Purpose, Industrial, Telecommunications
- Operating Temperature Min
- -40°C
- Contact Type
- Male Pin
- Connector Type
- Header
- Mixed Contacts
- YES
- Insulation Color
- Black
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Contact Length Post
- 0.147 3.73mm
- Montaj Tipi
- Through Hole
- Number Of Conductors
- ONE
- RoHS Durumu
- ROHS3 Compliant
- Contact Finish Mating
- Gold
- Kurşunsuz Kodu
- yes
- Length Termination
- 0.147 inch
- Contact Materials
- Copper
- Contact Finish Post
- Tin
