Volume pricing
- 1+ pcs$0.79
- 10+ pcs$0.75
- 100+ pcs$0.71
- 500+ pcs$0.67
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Mixed Contacts
- NO
- Pcb Contact Pattern
- RECTANGULAR
- Fabrika Tedarik Süresi
- 14 Weeks
- Parça Durumu
- Active
- Ambalaj
- Tape & Reel (TR)
- Number Of Positions Loaded
- All
- Number Of Pcb Rows
- 1
- Pitch Mating
- 0.100 2.54mm
- Yayın Yılı
- 2014
- Connector Type
- Header
- Applications
- Automotive, General Purpose, Medical, Telecommunications
- Insulation Materials
- Polyamide (PA), Nylon
- Contact Type
- Male Pin
- Mounting Option1
- LOCKING
- Sıra Sayısı
- 1
- Pozisyon Sayısı
- 4
- Contact Finish Thickness Mating
- 60.0μin 1.52μm
- Plating Thickness
- 60μin
- Contact Finish Thickness Post
- 60.0μin 1.52μm
- Montaj Tipi
- Through Hole, Right Angle
- Contact Materials
- Brass
- Terminal
- Solder
- RoHS Durumu
- ROHS3 Compliant
- Seri
- KK 171857
- Shrouding
- Shrouded - 1 Wall
- Contact Length Post
- 0.100 2.54mm
- Insulation Height
- 0.250 6.35mm
- Insulation Color
- Black
- Fastening Type
- Friction Lock
- Material Flammability Rating
- UL94 V-2
- Reference Standard
- UL
- Contact Shape
- Square
- Filter Feature
- NO
- Body Breadth
- 0.25 inch
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Lengthmating
- 0.265 6.73mm
- Contact Finish Mating
- Tin
- Style
- Board to Board or Cable
