Specifications
- Insulation Materials
- Polyamide (PA), Nylon
- Applications
- Automotive, General Purpose, Medical, Telecommunications
- Yayın Yılı
- 2014
- Connector Type
- Header
- Pitch Mating
- 0.100 2.54mm
- Number Of Positions Loaded
- All
- Ambalaj
- Tape & Reel (TR)
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 14 Weeks
- RoHS Durumu
- ROHS3 Compliant
- Terminal
- Solder
- Contact Materials
- Brass
- Montaj Tipi
- Through Hole, Right Angle
- Contact Finish Thickness Post
- 60.0μin 1.52μm
- Contact Finish Thickness Mating
- 60.0μin 1.52μm
- Pozisyon Sayısı
- 3
- Sıra Sayısı
- 1
- Contact Type
- Male Pin
- Material Flammability Rating
- UL94 V-2
- Insulation Color
- Black
- Fastening Type
- Friction Lock
- Insulation Height
- 0.250 6.35mm
- Contact Length Post
- 0.100 2.54mm
- Shrouding
- Shrouded - 1 Wall
- Seri
- KK 171857
- Style
- Board to Board or Cable
- Contact Lengthmating
- 0.265 6.73mm
- Contact Finish Mating
- Tin
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Shape
- Square
