Specifications
- Seri
- KK 171856
- Shrouding
- Shrouded - 1 Wall
- Contact Length Post
- 0.092 2.34mm
- Insulation Height
- 0.322 8.18mm
- Contact Finish Post
- Tin
- Material Flammability Rating
- UL94 V-2
- Insulation Color
- Black
- Fastening Type
- Friction Lock
- Contact Shape
- Square
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Lengthmating
- 0.293 7.45mm
- Contact Finish Mating
- Gold
- Style
- Board to Board or Cable
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 11 Weeks
- Ambalaj
- Tape & Reel (TR)
- Number Of Positions Loaded
- All
- Pitch Mating
- 0.100 2.54mm
- Montaj
- Through Hole
- Applications
- Automotive, General Purpose, Medical, Telecommunications
- Connector Type
- Header
- Yayın Yılı
- 2016
- Insulation Materials
- Polyamide (PA), Nylon
- Contact Type
- Male Pin
- Sıra Sayısı
- 1
- Orientation
- Vertical
- Pozisyon Sayısı
- 4
- Özellikler
- Pick and Place
- Contact Finish Thickness Mating
- 15.0μin 0.38μm
- Contact Materials
- Brass
- Montaj Tipi
- Through Hole
- Contact Finish Thickness Post
- 100.0μin 2.54μm
- RoHS Durumu
- ROHS3 Compliant
- Overall Contact Length
- 0.510 12.95mm
- Terminal
- Solder
