1718133006

Specifications

Insulation Materials

Polyamide (PA), Nylon

Style

Board to Board or Cable

Nem Hassasiyeti (MSL)

1 (Unlimited)

Contact Length Post

0.093 2.35mm

Ambalaj

Tape & Reel (TR)

Contact Lengthmating

0.448 11.38mm

Applications

Automotive, General Purpose, Industrial, Medical, Telecommunications

Connector Type

Header

Contact Finish Thickness Mating

60.0μin 1.52μm

Insulation Height

0.446 11.33mm

Montaj Tipi

Through Hole

Contact Finish Mating

Tin

Contact Type

Male Pin

Parça Durumu

Active

Yayın Yılı

2014

RoHS Durumu

ROHS3 Compliant

Fastening Type

Friction Lock

Fabrika Tedarik Süresi

14 Weeks

Number Of Positions Loaded

All

Contact Materials

Brass

Pozisyon Sayısı

6

Terminal

Solder

Shrouding

Shrouded - 1 Wall

Özellikler

Pick and Place

Pitch Mating

0.156 3.96mm

Contact Shape

Square

Material Flammability Rating

UL94 V-2

Overall Contact Length

0.671 17.05mm

Insulation Color

Black

Contact Finish Thickness Post

60.0μin 1.52μm

Sıra Sayısı

1

Seri

KK 171813
