Specifications
- Fastening Type
- Friction Lock
- Number Of Conductors
- ONE
- Fabrika Tedarik Süresi
- 12 Weeks
- Number Of Positions Loaded
- All
- Contact Materials
- Brass
- Pozisyon Sayısı
- 9
- Durability
- 25 Cycles
- Shrouding
- Shrouded - 1 Wall
- Terminal
- Solder
- Number Of Pcb Rows
- 1
- Pitch Mating
- 0.156 3.96mm
- Contact Shape
- Square
- Material Flammability Rating
- UL94 V-2
- Overall Contact Length
- 0.671 17.05mm
- Reference Standard
- UL, CSA
- Rated Current Signal
- 7A
- Insulation Color
- Black
- Contact Finish Thickness Post
- 60.0μin 1.52μm
- Seri
- KK 171813
- Sıra Sayısı
- 1
- Pcb Contact Pattern
- RECTANGULAR
- Reliability
- COMMERCIAL
- Insulation Materials
- Polyamide (PA), Nylon
- Style
- Board to Board or Cable
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Length Post
- 0.093 2.35mm
- Ambalaj
- Bulk
- Operating Temperature Min
- -40°C
- Contact Lengthmating
- 0.448 11.38mm
- Applications
- Automotive, General Purpose, Industrial, Medical, Telecommunications
- Connector Type
- Header
- Insulation Height
- 0.446 11.33mm
- Contact Finish Thickness Mating
- 60.0μin 1.52μm
- Montaj Tipi
- Through Hole
- Body Depth
- 0.446 inch
- Contact Type
- Male Pin
- Contact Finish Mating
- Tin
- Parça Durumu
- Active
- RoHS Durumu
- ROHS3 Compliant
- Yayın Yılı
- 2013
