Specifications
- Rated Current Signal
- 1A
- Contact Finish Thickness
- 30.0μin 0.76μm
- Polarization Key
- POLARIZED HOUSING
- Mating Contact Pitch
- 0.03 inch
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Insulation Materials
- GLASS FILLED THERMOPLASTIC
- Body Breadth
- 0.597 inch
- Parça Durumu
- Active
- Plating Thickness
- 30μin
- Number Of Conductors
- ONE
- Ambalaj
- Tray
- Pozisyon Sayısı
- 36
- Terminal
- Press-Fit
- Yayın Yılı
- 2015
- Contact Finish
- Gold
- Mounting Option2
- LOCKING
- Contact Pattern
- RECTANGULAR
- Mounting Option1
- LATCH
- Body Length Or Diameter
- 0.665 inch
- Montaj Tipi
- Through Hole
- Sıra Sayısı
- 4
- Operating Temperature Min
- -40°C
- RoHS Durumu
- ROHS3 Compliant
- Contact Gender
- FEMALE
- Length Termination
- 0.054 inch
- Operating Temperature Max
- 80°C
- Total Number Of Contacts
- 36
- Body Depth
- 0.559 inch
- Reference Standard
- UL, CSA
- Seri
- iPass 170729
- Durability
- 50 Cycles
- Dielectric Withstanding Voltage
- 300VDC V
- Connector Style
- Receptacle
- Contact Style
- BELLOWED TYPE
- Fabrika Tedarik Süresi
- 12 Weeks
- Reliability
- COMMERCIAL
- Kurşunsuz Kodu
- yes
- JESD-609 Kodu
- e3
