Specifications
- HTS Kodu
- 8536.69.40.40
- Terminal
- Solder
- Montaj Tipi
- Surface Mount, Right Angle
- Sıra Sayısı
- 1
- Contact Shape
- Square
- Material Flammability Rating
- UL94 V-0
- Pitch Mating
- 0.079 2.00mm
- Connector Type
- Header
- Parça Durumu
- Active
- Contact Lengthmating
- 0.141 3.60mm
- Contact Finish Thickness Post
- 78.7μin 2.00μm
- Contact Materials
- Copper Alloy
- Seri
- Milli-Grid 151064
- Contact Finish Mating
- Tin
- Style
- Board to Cable/Wire
- RoHS Durumu
- ROHS3 Compliant
- Insulation Color
- Black
- Pozisyon Sayısı
- 10
- Applications
- Automotive, General Purpose, Telecommunications
- Insulation Materials
- Liquid Crystal Polymer (LCP), Glass Filled
- Number Of Positions Loaded
- All
- Contact Type
- Male Pin
- Fastening Type
- Latch Holder
- Yayın Yılı
- 2016
- Insulation Height
- 0.263 6.67mm
- ECCN Kodu
- EAR99
- Shrouding
- Shrouded - 4 Wall
- Ambalaj
- Tube
- Contact Finish Thickness Mating
- 98.4μin 2.50μm
- Fabrika Tedarik Süresi
- 16 Weeks
