Specifications
- Insulation Color
- Natural
- Mixed Contacts
- NO
- Shrouding
- Shrouded - 4 Wall
- Contact Type
- Male Pin
- Additional Feature
- POLARIZED
- Mil Conformance
- NO
- Contact Shape
- Square
- Iec Conformance
- NO
- Terminal
- Solder
- Contact Materials
- Brass
- Contact Length Post
- 0.138 3.50mm
- Filter Feature
- NO
- Style
- Board to Cable/Wire
- Ambalaj
- Tray
- Özellikler
- Board Guide
- Fastening Type
- Latch Holder
- Contact Finish Post
- Tin
- Fabrika Tedarik Süresi
- 10 Weeks
- Empty Shell
- NO
- Connector Type
- Header
- Nominal Gerilim
- 250V
- Insulation Height
- 0.247 6.28mm
- Kurşunsuz Kodu
- yes
- Contact Finish Thickness Post
- 59.0μin 1.50μm
- Pitch Mating
- 0.098 2.50mm
- Yayın Yılı
- 2016
- Sıra Sayısı
- 2
- Pozisyon Sayısı
- 6
- Ul Flammability Code
- 94V-0
- Montaj Tipi
- Through Hole, Right Angle
- Parça Durumu
- Active
- RoHS Durumu
- ROHS3 Compliant
- Seri
- Nano-Fit 105314
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Contact Finish Mating
- Gold
- Row Spacing Mating
- 0.098 (2.50mm)
- Number Of Positions Loaded
- All
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Din Conformance
- NO
- Çalışma Sıcaklığı
- -40°C~105°C
