10-18-1090

Specifications

Number Of Conductors

ONE

Orientation

Vertical

Pitch

5.03mm

Sıra Sayısı

3

Row Spacing Mating

5.0292 mm

Iec Conformance

NO

Terminal

Solder

JESD-609 Kodu

e3

Contact Plating

Tin

Yayın Yılı

2005

Additional Feature

POLARIZED, SHROUDED

Body Depth

0.42 inch

Ambalaj

Bulk

Kurşunsuz Kodu

yes

Voltage Rated Dc

250V

Din Conformance

NO

Min. Çalışma Sıcaklığı

-40°C

Contact Materials

Brass

Reliability

COMMERCIAL

Renk

Black

Filter Feature

NO

Mil Conformance

NO

Body Length Or Diameter

0.77 inch

Montaj

Through Hole

RoHS Durumu

RoHS Compliant

Mixed Contacts

NO

Connector Type

Male Pin

Bodyshell Style

SOCKET

Fabrika Tedarik Süresi

8 Weeks

Durability

25 Cycles

Reference Standard

UL, CSA

Number Of Contacts

9

Contact Gender

Male

Housing Material

Polyester

Option

GENERAL PURPOSE

Length Termination

0.17 inch

Kurşunsuz

Contains Lead

Maks. Çalışma Sıcaklığı

105°C

Contact Style

RND PIN-SKT

Flammability Rating

UL94 V-2
