10-11-2053

Specifications

Glow Wire Compliant

Non-compliant

Sıra Sayısı

1

Reach Svhc

Unknown

Min. Çalışma Sıcaklığı

0°C

Halogen Free

Low Halogen

Additional Feature

SHROUDED

ECCN Kodu

EAR99

Flammability Rating

UL94 V-0

Filter Feature

NO

Housing Material

Nylon

Depth

12.9mm

Iec Conformance

NO

Parça Durumu

Active

Yayın Yılı

2009

Kurşunsuz

Lead Free

Reliability

COMMERCIAL

Contact Resistance

20mOhm

Contact Style

SQ PIN-SKT

Body Breadth

0.226 inch

Onay Kuruluşu

CSA, UL

Mating Information

MULTIPLE MATING PARTS AVAILABLE

Yükseklik

5.08mm

Uzunluk

13.26mm

Insulation Diametermin

0.06 inch

Bodyshell Style

PLUG

Reference Standard

UL, CSA

Number Of Contacts

5

Ul Flammability Code

94V-0

Maks. Çalışma Sıcaklığı

75°C

Fastening Type

Ramp

Renk

White

Fabrika Tedarik Süresi

8 Weeks

Contact Gender

Female

Din Conformance

NO

Kurşunsuz Kodu

yes

Terminal

Crimp

Pitch

2.54mm

Contact Pattern

RECTANGULAR

Orientation

Straight

Genişlik

5.08mm
