Specifications
- Connector Type
- Header
- Contact Shape
- Rectangular
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj
- Surface Mount
- Sıra Sayısı
- 1
- Style
- Board to Cable/Wire
- Contact Finish Thickness Mating
- 24.0μin 0.61μm
- Kurşunsuz Kodu
- yes
- Depth
- 6.9mm
- Number Of Circuits
- 6
- Contact Lengthmating
- 0.085 2.15mm
- Ambalaj
- Bulk
- Housing Color
- Beige
- Terminal
- Solder
- Pozisyon Sayısı
- 8
- Shrouding
- Shrouded - 2 Wall
- Min. Çalışma Sıcaklığı
- -40°C
- Contact Finish Thickness Post
- 118.1μin 3.00μm
- Fastening Type
- Push-Pull
- Contact Resistance
- 15mOhm
- Housing Material
- Nylon
- Max Voltage Rating Ac
- 250V
- Pitch Mating
- 0.050 1.27mm
- Insulation Height
- 0.161 4.10mm
- Insulation Color
- Natural
- Seri
- Picoflex PF-50 90814
- Parça Durumu
- Active
- RoHS Durumu
- ROHS3 Compliant
- Contact Materials
- Cartridge Brass
- Contact Type
- Male Blade
- Number Of Positions Loaded
- All
- Insulation Materials
- Polyamide (PA), Nylon, Glass Filled
- Radyasyon Dayanımı
- No
- Material Flammability Rating
- UL94 V-0
- Orientation
- Vertical
- Uzunluk
- 13.94mm
- Akım Değeri
- 2.4A
- Contact Finish Mating
- Palladium-Nickel
- Fabrika Tedarik Süresi
- 11 Weeks
- Current Rating Amps
- 1.2A
