0901361312

Specifications

Contact Materials

Brass

Number Of Positions Loaded

All

Depth

7.21mm

Housing Material

Polyester

Nem Hassasiyeti (MSL)

1 (Unlimited)

Contact Plating

Gold

Applications

Automotive, General Purpose

Contact Finish Thickness Post

118.1μin 3.00μm

Insulation Materials

Polyester, Glass Filled

Parça Durumu

Active

Min. Çalışma Sıcaklığı

-55°C

Overall Contact Length

0.510 12.95mm

Maks. Çalışma Sıcaklığı

125°C

Contact Length Post

0.114 2.90mm

Terminal

Solder

Style

Board to Cable/Wire

Number Of Circuits

10

Ambalaj

Tray

Contact Finish Thickness Mating

30.0μin 0.76μm

Pitch Mating

0.100 2.54mm

Contact Finish Mating

Gold

Seri

C-Grid III 90136

Material Flammability Rating

UL94 V-0

Montaj Tipi

Through Hole

Pitch

2.54mm

Contact Finish Post

Tin

Fastening Type

Latch Holder

Insulation Color

Black

Montaj

Through Hole

Insulation Height

0.429 10.90mm

Uzunluk

33.83mm

Connector Type

Header

RoHS Durumu

ROHS3 Compliant

Pozisyon Sayısı

12

Orientation

Vertical

Shrouding

Shrouded - 4 Wall

Contact Lengthmating

0.266 6.75mm

Sıra Sayısı

1

Contact Type

Male Pin

Contact Shape

Square
