Specifications
- Pitch Mating
- 0.100 2.54mm
- Contact Finish Mating
- Gold
- Seri
- C-Grid III 90131
- Ambalaj
- Tray
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Style
- Board to Cable/Wire
- Terminal
- Solder
- Contact Length Post
- 0.114 2.90mm
- Overall Contact Length
- 0.478 12.15mm
- Contact Finish Thickness Post
- 118.1μin 3.00μm
- Insulation Materials
- Polyester, Glass Filled
- Parça Durumu
- Active
- Applications
- Automotive, General Purpose
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Number Of Positions Loaded
- All
- Contact Materials
- Brass
- Row Spacing Mating
- 0.100 (2.54mm)
- Contact Type
- Male Pin
- Contact Shape
- Square
- Contact Lengthmating
- 0.266 6.75mm
- Shrouding
- Unshrouded
- Sıra Sayısı
- 2
- Pozisyon Sayısı
- 30
- Kurşunsuz Kodu
- yes
- Connector Type
- Header, Breakaway
- RoHS Durumu
- ROHS3 Compliant
- Fastening Type
- Push-Pull
- Insulation Color
- Black
- Montaj
- Through Hole
- Insulation Height
- 0.098 2.50mm
- Contact Finish Post
- Tin
- Material Flammability Rating
- UL94 V-0
- Montaj Tipi
- Through Hole
