Specifications
- Contact Type
- Male Pin
- Contact Shape
- Square
- Pozisyon Sayısı
- 18
- Mounting Option1
- LOCKING
- Shrouding
- Shrouded - 4 Wall
- Contact Lengthmating
- 0.266 6.75mm
- Sıra Sayısı
- 2
- Fastening Type
- Latch Holder
- ECCN Kodu
- EAR99
- Insulation Color
- Black
- Insulation Height
- 0.384 9.75mm
- Connector Type
- Header
- RoHS Durumu
- ROHS3 Compliant
- Material Flammability Rating
- UL94 V-0
- Montaj Tipi
- Through Hole, Right Angle
- Durability
- 100 Cycles
- Insulation Resistance
- 5000000000Ohm
- Contact Finish Post
- Tin
- Operating Temperature Min
- -55°C
- JESD-609 Kodu
- e3
- Ambalaj
- Tray
- Contact Finish Thickness Mating
- 15.0μin 0.38μm
- Pitch Mating
- 0.100 2.54mm
- Contact Finish Mating
- Gold
- Seri
- C-Grid III 90130
- Fabrika Tedarik Süresi
- 10 Weeks
- Contact Length Post
- 0.114 2.90mm
- Terminal
- Solder
- Style
- Board to Cable/Wire
- Plating Thickness
- 15μin
- Number Of Conductors
- ONE
- HTS Kodu
- 8536.69.40.40
- Applications
- Automotive, General Purpose
- Reliability
- COMMERCIAL
- Reference Standard
- UL, CSA
- Mating Contact Pitch
- 0.1 inch
- Contact Finish Thickness Post
- 118.1μin 3.00μm
- Parça Durumu
- Active
- Insulation Materials
- Polyester, Glass Filled
- Contact Materials
- Brass
