Specifications
- Contact Length Post
- 0.114 2.90mm
- Terminal
- Solder
- Style
- Board to Board or Cable
- Number Of Circuits
- 2
- Maks. Çalışma Sıcaklığı
- 125°C
- Contact Resistance
- 20mOhm
- Min. Çalışma Sıcaklığı
- -55°C
- Number Of Contacts
- 3
- Pitch Mating
- 0.100 2.54mm
- Gender
- Male
- Seri
- C-Grid III 90121
- Contact Finish Mating
- Gold
- Ambalaj
- Tray
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Housing Material
- Polyester
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Depth
- 11mm
- Contact Materials
- Brass
- Number Of Positions Loaded
- All
- Contact Finish Thickness Post
- 118.1μin 3.00μm
- Parça Durumu
- Active
- Insulation Materials
- Polyester, Glass Filled
- Applications
- Automotive, General Purpose
- Contact Plating
- Gold
- Contact Lengthmating
- 0.266 6.75mm
- Shrouding
- Unshrouded
- Orientation
- Right Angle
- Sıra Sayısı
- 1
- Akım Değeri
- 3A
- Pozisyon Sayısı
- 3
- Housing Color
- Black
- Contact Shape
- Square
- Contact Type
- Male Pin
- Renk
- Black
- Contact Finish Post
- Tin
- Pitch
- 2.54mm
- Montaj Tipi
- Through Hole, Right Angle
- Material Flammability Rating
- UL94 V-0
- Uzunluk
- 7.62mm
- Connector Type
- Header, Breakaway
