0878980554

Specifications

Pitch Mating

0.100 2.54mm

Applications

Automotive, General Purpose, Lighting, Medical, Telecommunications

Sıra Sayısı

1

Mixed Contacts

NO

Terminal

Solder

Contact Finish Thickness Mating

15.0μin 0.38μm

Mil Conformance

NO

Contact Type

Male Pin

Number Of Positions Loaded

All

Contact Materials

Copper Alloy

Fabrika Tedarik Süresi

13 Weeks

Contact Finish Post

Tin

Contact Finish Mating

Gold

Ambalaj

Tape & Reel (TR)

RoHS Durumu

ROHS3 Compliant

Contact Lengthmating

0.230 5.84mm

JESD-609 Kodu

e3

Contact Finish Thickness Post

78.7μin 2.00μm

Insulation Color

Black

Kurşunsuz Kodu

yes

Din Conformance

NO

Shrouding

Unshrouded

Parça Durumu

Active

Insulation Height

0.098 2.50mm

Montaj Tipi

Surface Mount

Material Flammability Rating

UL94 V-0

Total Number Of Contacts

5

Filter Feature

NO

Özellikler

Pick and Place

Pozisyon Sayısı

5

Seri

C-Grid SL 87898

Fastening Type

Push-Pull

Contact Shape

Square

Insulation Materials

Polyamide (PA), Nylon, Glass Filled

Connector Type

Header, Breakaway

Nem Hassasiyeti (MSL)

1 (Unlimited)

Style

Board to Board or Cable

Iec Conformance

NO
