0878970526

Specifications

Contact Length Post

0.090 2.29mm

Material Flammability Rating

UL94 V-0

Montaj Tipi

Through Hole, Right Angle

Insulation Height

0.099 2.51mm

Din Conformance

NO

Parça Durumu

Active

Shrouding

Unshrouded

Orientation

Right Angle

Housing Material

Nylon

Iec Conformance

NO

Number Of Contacts

5

Nem Hassasiyeti (MSL)

1 (Unlimited)

Style

Board to Board or Cable

Contact Shape

Square

Insulation Materials

Thermoplastic

Connector Type

Header, Breakaway

Seri

KK 87897

Fastening Type

Push-Pull

Filter Feature

NO

Housing Color

Black

Contact Finish Thickness Mating

100.0μin 2.54μm

Terminal

Solder

Sıra Sayısı

1

Mixed Contacts

NO

Montaj

Through Hole

Akım Değeri

3A

Uzunluk

12.7mm

Applications

Automotive, General Purpose, Medical, Telecommunications

Pitch Mating

0.100 2.54mm

Kurşunsuz Kodu

yes

Contact Finish Thickness Post

100.0μin 2.54μm

RoHS Durumu

ROHS3 Compliant

Ambalaj

Tube

Contact Lengthmating

0.230 5.84mm

Min. Çalışma Sıcaklığı

-55°C

Contact Finish Mating

Tin

Fabrika Tedarik Süresi

13 Weeks

Maks. Çalışma Sıcaklığı

105°C

Number Of Positions Loaded

All

Contact Materials

Copper Alloy
