0878580550

Specifications

Number Of Conductors

ONE

Kurşunsuz Kodu

yes

Contact Finish Thickness Post

100.0μin 2.54μm

Number Of Circuits

4

Depth

8mm

Min. Çalışma Sıcaklığı

-55°C

Contact Lengthmating

0.126 3.20mm

RoHS Durumu

ROHS3 Compliant

Ambalaj

Tape & Reel (TR)

Contact Finish Mating

Tin

Fabrika Tedarik Süresi

16 Weeks

Maks. Çalışma Sıcaklığı

105°C

Number Of Positions Loaded

All

Contact Materials

Copper Alloy

Contact Type

Male Pin

Reliability

COMMERCIAL

Housing Color

Black

Terminal

Solder

Contact Finish Thickness Mating

100.0μin 2.54μm

Sıra Sayısı

1

Montaj

Surface Mount

Akım Değeri

2A

Uzunluk

9.9mm

Applications

Automotive, General Purpose, Telecommunications

Pitch Mating

0.079 2.00mm

Housing Material

Polymer

Orientation

Right Angle

Style

Board to Board or Cable

Nem Hassasiyeti (MSL)

1 (Unlimited)

Connector Type

Header, Breakaway

Insulation Materials

Liquid Crystal Polymer (LCP), Glass Filled

Contact Shape

Square

Seri

Milli-Grid 87858

Fastening Type

Push-Pull

Rated Current Signal

2A

Özellikler

Pick and Place

Pozisyon Sayısı

5

Terminal Adımı

2.0066mm

Total Number Of Contacts

5

Mating Contact Pitch

0.079 inch
