Specifications
- Contact Type
- Male Pin
- Mil Conformance
- NO
- Glow Wire Compliant
- Non-compliant
- Fabrika Tedarik Süresi
- 10 Weeks
- Radyasyon Dayanımı
- No
- Contact Lengthmating
- 0.141 3.60mm
- Min. Çalışma Sıcaklığı
- -55°C
- Contact Finish Post
- Tin
- Contact Finish Mating
- Gold
- Kurşunsuz Kodu
- yes
- Insulation Color
- Black
- Sıra Sayısı
- 2
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
- Terminal
- Solder
- Özellikler
- Keying Slot
- Connector Type
- Header
- Contact Shape
- Square
- Style
- Board to Board or Cable
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Orientation
- Right Angle
- Housing Material
- Thermoplastic
- Iec Conformance
- NO
- Shrouding
- Shrouded - 4 Wall
- Montaj Tipi
- Through Hole, Right Angle
- Insulation Height
- 0.248 6.30mm
- Contact Length Post
- 0.085 2.16mm
- Contact Materials
- Phosphor Bronze
- Number Of Positions Loaded
- All
- Maks. Çalışma Sıcaklığı
- 105°C
- Ambalaj
- Tube
- Ul Flammability Code
- 94V-0
- RoHS Durumu
- ROHS3 Compliant
- JESD-609 Kodu
- e3
- Contact Finish Thickness Post
- 74.8μin 1.90μm
- Applications
- Automotive, General Purpose, Telecommunications
- Pitch Mating
- 0.079 2.00mm
- Akım Değeri
- 2A
- Mixed Contacts
- NO
- Montaj
- Through Hole
- Filter Feature
- NO
