0877604616

Specifications

Montaj Tipi

Through Hole, Right Angle

Contact Lengthmating

0.157 4.00mm

Seri

Milli-Grid 87760

Contact Finish Mating

Gold

Shrouding

Unshrouded

Applications

Automotive, General Purpose, Telecommunications

Fastening Type

Push-Pull

Terminal

Solder

Sıra Sayısı

2

Fabrika Tedarik Süresi

22 Weeks

Connector Type

Header

Ambalaj

Tray

Pozisyon Sayısı

46

Contact Finish Post

Tin

Number Of Positions Loaded

All

Nem Hassasiyeti (MSL)

1 (Unlimited)

Contact Materials

Phosphor Bronze

Row Spacing Mating

0.079 (2.00mm)

Contact Finish Thickness Post

78.7μin 2.00μm

Contact Type

Male Pin

Parça Durumu

Active

Insulation Materials

Polycyclohexylenedimethylene Terephthalate (PCT), Glass Filled

Insulation Height

0.169 4.30mm

RoHS Durumu

ROHS3 Compliant

Contact Shape

Square

Pitch Mating

0.079 2.00mm

Contact Finish Thickness Mating

15.0μin 0.38μm

Contact Length Post

0.102 2.60mm

Style

Board to Board or Cable

Material Flammability Rating

UL94 V-0

Insulation Color

Black
