0877596005

Specifications

Kurşunsuz Kodu

yes

Style

Board to Board or Cable

Material Flammability Rating

UL94 V-0

Depth

6.6mm

Pitch Mating

0.079 2.00mm

Contact Shape

Square

RoHS Durumu

ROHS3 Compliant

Insulation Height

0.059 1.50mm

Contact Finish Thickness Mating

10.0μin 0.25μm

Housing Color

Black

Parça Durumu

Active

Insulation Materials

Polyamide (PA), Nylon, Glass Filled

Row Spacing Mating

0.079 (2.00mm)

Contact Materials

Copper Alloy

Contact Type

Male Pin

Contact Finish Thickness Post

100.0μin 2.54μm

Contact Finish Post

Tin

Number Of Positions Loaded

43

Nem Hassasiyeti (MSL)

1 (Unlimited)

Özellikler

Board Guide, Pick and Place

Pozisyon Sayısı

44

Ambalaj

Tape & Reel (TR)

Montaj

Surface Mount

Fabrika Tedarik Süresi

15 Weeks

Connector Type

Header, Breakaway

Fastening Type

Push-Pull

Terminal

Solder

Sıra Sayısı

2

Uzunluk

43.9mm

Applications

Automotive, General Purpose, Telecommunications

Shrouding

Unshrouded

Min. Çalışma Sıcaklığı

-55°C

Maks. Çalışma Sıcaklığı

105°C

Contact Finish Mating

Gold

Housing Material

Nylon

Orientation

Straight

Montaj Tipi

Surface Mount

Contact Lengthmating

0.126 3.20mm

Seri

Milli-Grid 87759
