Specifications
- Applications
- Automotive, General Purpose, Telecommunications
- Shrouding
- Unshrouded
- Contact Finish Mating
- Gold
- Montaj Tipi
- Surface Mount
- Contact Lengthmating
- 0.150 3.81mm
- Seri
- Milli-Grid 87759
- Pozisyon Sayısı
- 8
- Ambalaj
- Tape & Reel (TR)
- Fabrika Tedarik Süresi
- 12 Weeks
- Connector Type
- Header, Breakaway
- Terminal
- Solder
- Fastening Type
- Push-Pull
- Sıra Sayısı
- 2
- Insulation Materials
- Polyamide (PA), Nylon
- Parça Durumu
- Active
- Row Spacing Mating
- 0.079 (2.00mm)
- Contact Materials
- Phosphor Bronze
- Contact Type
- Male Pin
- Contact Finish Post
- Tin
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Number Of Positions Loaded
- All
- Özellikler
- Pick and Place
- Kurşunsuz Kodu
- yes
- Insulation Color
- Black
- Style
- Board to Board or Cable
- Material Flammability Rating
- UL94 V-0
- Pitch Mating
- 0.079 2.00mm
- Contact Shape
- Square
- Insulation Height
- 0.059 1.50mm
- RoHS Durumu
- ROHS3 Compliant
- Contact Finish Thickness Mating
- 30.0μin 0.76μm
