Specifications
- Mixed Contacts
- NO
- JESD-609 Kodu
- e3
- Montaj
- Surface Mount
- Ambalaj
- Tube
- Filter Feature
- NO
- Sıra Sayısı
- 2
- Number Of Contacts
- 4
- Fastening Type
- Push-Pull
- Terminal
- Solder
- Connector Type
- Header, Breakaway
- Fabrika Tedarik Süresi
- 12 Weeks
- Maks. Çalışma Sıcaklığı
- 105°C
- Contact Finish Mating
- Gold
- Min. Çalışma Sıcaklığı
- -55°C
- Mil Conformance
- NO
- Shrouding
- Unshrouded
- Applications
- Automotive, General Purpose, Telecommunications
- Radyasyon Dayanımı
- No
- Seri
- Milli-Grid 87759
- Contact Lengthmating
- 0.150 3.81mm
- Montaj Tipi
- Surface Mount
- Orientation
- Vertical
- Housing Material
- Thermoplastic
- Din Conformance
- NO
- Depth
- 5.5mm
- Material Flammability Rating
- UL94 V-0
- Style
- Board to Board or Cable
- Kurşunsuz Kodu
- yes
- Contact Finish Thickness Mating
- 15.0μin 0.38μm
- Iec Conformance
- NO
- Pitch Mating
- 0.079 2.00mm
- Contact Shape
- Square
- RoHS Durumu
- ROHS3 Compliant
- Insulation Height
- 0.059 1.50mm
- Contact Type
- Male Pin
- Row Spacing Mating
- 0.079 (2.00mm)
- Contact Materials
- Phosphor Bronze
- Parça Durumu
- Active
- Insulation Materials
- Polyamide (PA), Nylon, Glass Filled
- Akım Değeri
- 2A
