0877583017

Specifications

Insulation Height

0.059 1.50mm

RoHS Durumu

ROHS3 Compliant

Contact Shape

Square

Pitch Mating

0.079 2.00mm

Contact Finish Thickness Mating

30.0μin 0.76μm

Contact Length Post

0.102 2.60mm

Style

Board to Board or Cable

Pitch

2mm

Material Flammability Rating

UL94 V-0

Depth

4mm

Insulation Color

Black

Number Of Circuits

30

Contact Finish Post

Tin

Number Of Positions Loaded

All

Nem Hassasiyeti (MSL)

1 (Unlimited)

Contact Materials

Phosphor Bronze

Row Spacing Mating

0.079 (2.00mm)

Contact Type

Male Pin

Housing Color

Black

Akım Değeri

2A

Parça Durumu

Active

Insulation Materials

Polyamide (PA46), Nylon 4/6, Glass Filled

Contact Plating

Gold

Terminal

Solder

Fastening Type

Push-Pull

Number Of Contacts

30

Sıra Sayısı

2

Fabrika Tedarik Süresi

12 Weeks

Connector Type

Header, Breakaway

Ambalaj

Tray

Montaj

Through Hole

Pozisyon Sayısı

30

Overall Contact Length

0.319 8.10mm

Contact Lengthmating

0.157 4.00mm

Montaj Tipi

Through Hole

Orientation

Vertical

Seri

Milli-Grid 87758

Housing Material

Nylon

Min. Çalışma Sıcaklığı

-55°C

Renk

Black
