Specifications
- Contact Shape
- Square
- Contact Type
- Male Pin
- Mixed Contacts
- NO
- Iec Conformance
- NO
- Shrouding
- Shrouded - 4 Wall
- Kurşunsuz Kodu
- yes
- Pozisyon Sayısı
- 2
- Connector Type
- Header
- RoHS Durumu
- ROHS3 Compliant
- Insulation Height
- 0.394 10.00mm
- Insulation Color
- Beige
- Ul Flammability Code
- 94V-0
- Fastening Type
- Locking Ramp
- JESD-609 Kodu
- e3
- Empty Shell
- NO
- Din Conformance
- NO
- Montaj Tipi
- Through Hole, Right Angle
- Material Flammability Rating
- UL94 V-0
- Seri
- Mini-Fit Jr 87427
- Contact Finish Mating
- Tin
- Contact Finish Thickness Mating
- 100.0μin 2.54μm
- Ambalaj
- Tray
- Fabrika Tedarik Süresi
- 7 Weeks
- Style
- Board to Cable/Wire
- Terminal
- Solder
- Contact Length Post
- 0.130 3.30mm
- Mil Conformance
- NO
- Additional Feature
- POLARIZED
- Filter Feature
- NO
- Parça Durumu
- Active
- Insulation Materials
- Polyamide (PA46), Nylon 4/6
- Contact Finish Thickness Post
- 100.0μin 2.54μm
- Applications
- General Purpose, Industrial, Telecommunications
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Row Spacing Mating
- 0.165 (4.20mm)
- Contact Materials
- Brass
- Number Of Positions Loaded
- All
