Specifications
- Rated Current Signal
- 1A
- Contact Materials
- Copper Alloy
- Contact Finish Thickness
- 30.0μin 0.76μm
- Height Above Board
- 0.546 13.87mm
- Çalışma Sıcaklığı
- 0°C~70°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Applications
- 10/100/1000 Base-T, AutoMDIX
- Fabrika Tedarik Süresi
- 21 Weeks
- Özellikler
- Board Lock
- Shielding
- Shielded, EMI Finger
- Number Of Cores Per Jack
- 8
- Montaj Tipi
- Through Hole
- Reliability
- COMMERCIAL
- Shield Material
- Stainless Steel
- Housing Material
- Polybutylene Terephthalate (PBT)
- Insulator Color
- BLACK
- Kurşunsuz Kodu
- yes
- Terminal
- Solder
- Mounting Option1
- LOCKING
- Bodyshell Style
- JACK
- Total Number Of Contacts
- 8
- Tab Direction
- Up
- Insulation Resistance
- 500000000Ohm
- Number Of Ports
- 1
- Contact Finish
- Gold
- Connector Type
- RJ45
- Contact Style
- TELCOM, MODULAR
- Contact Gender
- MALE
- Led Color
- Green - Yellow
- Orientation
- 90° Angle (Right)
- RoHS Durumu
- ROHS3 Compliant
- JESD-609 Kodu
- e3
- Durability
- 750 Cycles
- Contact Resistance
- 20mOhm
- Seri
- 85793
- Ambalaj
- Tray
- Parça Durumu
- Active
