Specifications
- Parça Durumu
- Active
- Pitch
- 0.100 2.54mm
- Ambalaj
- Tray
- Contact Finish
- Gold
- Din Conformance
- YES
- Pozisyon Sayısı
- 48
- Connector Type
- Header, Male Pins
- Mil Conformance
- NO
- Montaj Tipi
- Through Hole, Right Angle
- Sıra Sayısı
- 3
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Çalışma Sıcaklığı
- -55°C~125°C
- Contact Finish Thickness
- 24.0μin 0.61μm
- Option
- GENERAL PURPOSE
- Total Number Of Contacts
- 48
- Level Class
- 2
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Seri
- 85003
- Mixed Contacts
- NO
- Terminal
- Solder
- Ul Flammability Code
- 94V-0
- Fabrika Tedarik Süresi
- 10 Weeks
- Contact Materials
- NOT SPECIFIED
- Number Of Positions Loaded
- All
- Material Flammability Rating
- UL94 V-0
- Iec Conformance
- YES
- Material Insulation
- Polyester Thermoplastic
- Kurşunsuz Kodu
- yes
- Filter Feature
- NO
- Style
- C/2 (1/2 C)
- RoHS Durumu
- ROHS3 Compliant
