Specifications
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Additional Feature
- SHIELDED, POLARIZED
- Özellikler
- Board Lock, Shielded
- Connector Type
- Plug, Male Pins
- Connector Style
- D-Type, Micro-D
- Seri
- Commercial Micro-D Series 83612
- Çalışma Sıcaklığı
- -40°C~125°C
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Material Flammability Rating
- UL94 V-0
- Housing Material
- Polymer
- Mil Conformance
- NO
- Contact Type
- Signal
- Pitch
- 1.27mm
- Sıra Sayısı
- 2
- Number Of Circuits
- 9
- Pozisyon Sayısı
- 15
- Flange Feature
- Housing/Shell (2-56)
- Mixed Contacts
- NO
- Shell Material Finish
- Steel, Nickel Plated
- Terminal
- Solder
- Empty Shell
- NO
- Contact Materials
- Copper Alloy
- Dielectric Material
- Liquid Crystal Polymer (LCP)
- Filter Feature
- NO
- RoHS Durumu
- ROHS3 Compliant
- Contact Finish Thickness
- 15.0μin 0.38μm
- Option
- GENERAL PURPOSE
- Contact Finish
- Gold
- Akım Değeri
- 1A
- Shell Size Connector Layout
- 0.050 Pitch x 0.050 Row to Row
- Uzunluk
- 23.75mm
- Montaj Tipi
- Panel Mount, Through Hole, Right Angle
- Ambalaj
- Tube
- Din Conformance
- NO
- Orientation
- Right Angle
- Total Number Of Contacts
- 15
- Kurşunsuz Kodu
- yes
- Iec Conformance
- NO
- Montaj
- Panel, Through Hole
