Volume pricing
- 1+ pcs$1.95
- 10+ pcs$1.84
- 100+ pcs$1.74
- 500+ pcs$1.64
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Style
- Board to Cable/Wire
- Terminal
- Solder
- Ambalaj
- Tray
- Number Of Positions Loaded
- All
- JESD-609 Kodu
- e3
- Pitch Mating
- 0.224 5.70mm
- Contact Length Post
- 0.142 3.60mm
- Seri
- Mega-Fit
- Shrouding
- Shrouded - 4 Wall
- Montaj Tipi
- Through Hole, Right Angle
- Material Flammability Rating
- UL94 V-0
- Filter Feature
- NO
- Row Spacing Mating
- 0.224 (5.70mm)
- Contact Finish Mating
- Tin
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Iec Conformance
- NO
- Sıra Sayısı
- 2
- RoHS Durumu
- ROHS3 Compliant
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Pozisyon Sayısı
- 4
- Insulation Color
- Black
- ECCN Kodu
- EAR99
- Insulation Height
- 0.572 14.53mm
- Özellikler
- Board Guide, Glow Wire Compliant
- Shell Material
- POLYETHYLENE
- Additional Feature
- POLARIZED, SHROUDED
- Empty Shell
- NO
- Contact Materials
- Copper
- Connector Type
- Header
- Fabrika Tedarik Süresi
- 11 Weeks
- Mil Conformance
- NO
- Contact Finish Thickness Mating
- 60.0μin 1.52μm
- Fastening Type
- Locking Ramp
- Applications
- Automotive, General Purpose, Industrial, Telecommunications
- Mixed Contacts
- NO
- Din Conformance
- NO
- Contact Type
- Male Pin
- Contact Finish Thickness Post
- 60.0μin 1.52μm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
