Volume pricing
- 1+ pcs$1.87
- 10+ pcs$1.76
- 100+ pcs$1.66
- 500+ pcs$1.57
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Filter Feature
- NO
- Contact Lengthmating
- 0.441 11.20mm
- Contact Finish Thickness Post
- 100.0μin 2.54μm
- Montaj Tipi
- Through Hole
- Iec Conformance
- NO
- Terminal Adımı
- 3.5mm
- Montaj
- Through Hole
- Material Flammability Rating
- UL94 V-0
- Fastening Type
- Push-Pull
- Terminal
- Solder
- Uzunluk
- 15.7mm
- Kurşunsuz Kodu
- yes
- Insulation Materials
- Liquid Crystal Polymer (LCP), Glass Filled
- Row Spacing Mating
- 0.236 (6.00mm)
- Housing Material
- Polymer
- Pitch Mating
- 0.138 3.50mm
- Contact Finish Thickness Mating
- 100.0μin 2.54μm
- Contact Shape
- Square
- ECCN Kodu
- EAR99
- Max Voltage Rating Dc
- 500V
- Parça Durumu
- Active
- Ambalaj
- Tube
- Depth
- 9.6mm
- Contact Finish Mating
- Tin
- Seri
- MX150 75757
- Applications
- Automotive
- Sıra Sayısı
- 2
- Contact Length Post
- 0.120 3.05mm
- Contact Type
- Male Pin
- Overall Contact Length
- 0.738 18.75mm
- Din Conformance
- NO
- Min. Çalışma Sıcaklığı
- -40°C
- Shrouding
- Unshrouded
- RoHS Durumu
- ROHS3 Compliant
- Orientation
- Vertical
- Number Of Circuits
- 8
- Pozisyon Sayısı
- 12
- Maks. Çalışma Sıcaklığı
- 125°C
- Fabrika Tedarik Süresi
- 9 Weeks
- Connector Type
- Header, Breakaway
