Specifications
- Contact Shape
- Square
- Style
- Board to Cable/Wire
- Özellikler
- Board Guide
- Nominal Gerilim
- 250V
- Contact Type
- Male Pin
- Number Of Positions Loaded
- All
- Ambalaj
- Tube
- Pozisyon Sayısı
- 18
- Parça Durumu
- Active
- Fastening Type
- Latch Holder
- Shrouding
- Shrouded - 4 Wall
- Terminal
- Solder
- Kurşunsuz Kodu
- yes
- Pitch Mating
- 0.100 2.54mm
- Contact Length Post
- 0.130 3.30mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Finish Mating
- Tin
- Contact Lengthmating
- 0.240 6.10mm
- Insulation Materials
- Polyester, Glass Filled
- Applications
- Automotive, General Purpose, Industrial, Medical
- Contact Finish Thickness Mating
- 150.0μin 3.81μm
- Connector Type
- Header
- Çalışma Sıcaklığı
- -40°C~105°C
- Fabrika Tedarik Süresi
- 7 Weeks
- RoHS Durumu
- ROHS3 Compliant
- Seri
- SL 70555
- Material Flammability Rating
- UL94 V-0
- Sıra Sayısı
- 1
- Contact Finish Thickness Post
- 150.0μin 3.81μm
- Montaj Tipi
- Through Hole, Right Angle
- Insulation Height
- 0.215 5.45mm
- Contact Materials
- Phosphor Bronze
- Insulation Color
- Black
