Specifications
- Contact Finish Thickness Mating
- 15.0μin 0.38μm
- Insulation Materials
- Polyester, Glass Filled
- Applications
- Automotive, General Purpose, Industrial, Medical
- Contact Lengthmating
- 0.240 6.10mm
- Contact Finish Mating
- Gold
- Çalışma Sıcaklığı
- -40°C~105°C
- Connector Type
- Header
- RoHS Durumu
- ROHS3 Compliant
- Seri
- SL 70551
- Rated Current Signal
- 3A
- Fabrika Tedarik Süresi
- 5 Weeks
- Reliability
- COMMERCIAL
- Sıra Sayısı
- 1
- Material Flammability Rating
- UL94 V-0
- Montaj Tipi
- Through Hole, Right Angle
- Contact Finish Thickness Post
- 74.8μin 1.90μm
- Insulation Height
- 0.215 5.45mm
- Contact Materials
- Phosphor Bronze
- Insulation Color
- Black
- JESD-609 Kodu
- e3
- Style
- Board to Cable/Wire
- Contact Shape
- Square
- Orientation
- Right Angle
- Durability
- 50 Cycles
- REACH Uyumluluk Kodu
- unknown
- ECCN Kodu
- EAR99
- Contact Type
- Male Pin
- Nominal Gerilim
- 250V
- Reference Standard
- UL, CSA
- Özellikler
- Board Lock
- Ambalaj
- Bulk
- Pozisyon Sayısı
- 4
- Number Of Positions Loaded
- All
- Material
- Brass
- Shrouding
- Shrouded - 4 Wall
- Number Of Circuits
- 3
- Fastening Type
- Latch Holder
- Parça Durumu
- Active
- Akım Değeri
- 3A
- Contact Finish Post
- Tin
