Specifications
- Terminal
- Solder
- Contact Length Post
- 0.130 3.30mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Number Of Conductors
- ONE
- Mounting Option1
- LOCKING
- Pitch Mating
- 0.100 2.54mm
- Shrouding
- Shrouded - 4 Wall
- Parça Durumu
- Active
- Fastening Type
- Latch Holder
- Contact Finish Post
- Tin
- Contact Type
- Male Pin
- Nominal Gerilim
- 250V
- Özellikler
- Board Guide
- Reference Standard
- UL, CSA
- Pozisyon Sayısı
- 4
- Ambalaj
- Tube
- Number Of Positions Loaded
- All
- Overall Contact Length
- 0.470 11.94mm
- Style
- Board to Cable/Wire
- Contact Shape
- Square
- Durability
- 50 Cycles
- ECCN Kodu
- EAR99
- Contact Materials
- Phosphor Bronze
- Insulation Color
- Black
- JESD-609 Kodu
- e3
- Montaj Tipi
- Through Hole
- Contact Finish Thickness Post
- 74.8μin 1.90μm
- Contact Resistance
- 30mOhm
- Insulation Height
- 0.465 11.80mm
- RoHS Durumu
- ROHS3 Compliant
- Seri
- SL 70545
- Rated Current Signal
- 3A
- Fabrika Tedarik Süresi
- 8 Weeks
- Reliability
- COMMERCIAL
- Sıra Sayısı
- 1
- Material Flammability Rating
- UL94 V-0
- Contact Finish Thickness Mating
- 15.0μin 0.38μm
- Applications
- Automotive, General Purpose, Industrial, Medical
- Insulation Materials
- Polyester, Glass Filled
- Contact Finish Mating
- Gold
